MTX-Series rammers are renowned for performance and ease of operation. The MTX-Series includes the features most preferred by contractors such as:

• Cyclonic air cleaners that capture 98% of airborne dust particles
• Long-lasting laminated wood and steel shoe
• Low vibration handles for operator comfort
• Combination hour meter/tachometer
• Durable guards to protect the engine from damage
• Redesigned fuel tank to meet EPA standards for evaporative emmissions
• Visit mfg. website for more info: www.multiquip.com/multiquip/MTX80HDR.htm
• Prices, features and equipment specs. are subject to change without notice.

• Unit Specifications

  Blows Per Min.	Up to 678*
  Impact Force	3,505 lbf	1590 kN
  Shoe Jump Height	3.1 in	79 mm
  Shoe Dimensions (LxW)	13.4 x 11.2 in 340 x 285 mm
  Travel Speed Per Min.	49.2 ft	15 m
  Fuel Tank Capacity	2.7 qt	2.5 L
  Notes: *Variable speed impact — up to maximum impact force.

  Dimensions & Weights

  Overall Length	31.0 in	788 mm
  Overall Width	14.4 in	365 mm
  Overall Height	40.4 in	1027 mm
  Operating Weight	181 lb	82 kg

  Engine Specifications

  Engine Make/Model	Honda GXR120
  Start Method	Recoil
  Engine Power	3.6 HP	2.7 kW
  Engine RPM	4100
  Fuel Type	Gasoline
