• Brushless generator design requiring less maintenance
• 100% copper windings for maximum conductivity
• Lightweight and compact design for easy transport
• Twin duplex receptacles and three T-Lock receptacles for job site versatility
• Heavy-duty 1-inch (25 mm) steel pipe frame and shock mounts protect the generator
• Wheel kit - Hour meter - Folding lifting bale are now standard equipment
• Powered by Honda's GX-340 engine with low-oil shutdown and automatic idle control.
• Full panel GFCI protection - OSHA and NEC compliant
• Visit mfg. website for more info: https://www.multiquip.com/multiquip/GA6HR.htm

• Unit Specifications

  Alternator Design	Brushless
  Frequency	60 hz
  Phase	Single Phase
  Voltage	120/240 V
  Sound level at 30 ft.	75 dBA
  Fuel Tank Capacity	5 gal	19 L

  Power Generation

  	Maximum	Continuous
  Watts	6000 W	5000 W
  Amps at 120V	50 A	41.6 A
  Amps at 240V	25 A	20.8 A

  Receptacles & Circuit Breakers

  Main Circuit Breaker	23 A
  Number of Poles	2
  1 Receptacle of Each:	L5-20R 125V T-Lock 20A L5-30R 125V T-Lock 30A L14-30R 125/250V T-Lock 30A
  2 Receptacle of Each:	5-20R 125V GFCI 20A

  Dimensions & Weights

  Overall Length	27 in	69 mm
  Overall Width	22 in	56 mm
  Overall Height	24 in	61 mm
  Operating Weight	241 lb.	109 kg
  Shipping Weight	200 lb.	90 kg

  Engine Specifications

  Engine Make/Model	Honda GX-340
  Start Method	Recoil
  Engine Power	9.5 HP	7.9 kW
  Engine RPM	3600
  Fuel Type	Gasoline
